2-142 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Analog Inputs Parameters
Analog Input Configuration [Anlg Inp Config]
Linear Number: 652
Default Value: 0000000000000001
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter configures the hardware circuitry used on the ACB for sensing the three analog inputs.
The inputs can be configured to either accept 0-10V (Voltage) input or 4-20mA (Current) input. The
default value configures Analog Input 1 as a 4-20mA input.
Bit Enum Text Description
0 An1 0=V 1=mA Analog Input 1 enter – 0 for Voltage; 1 for Current
1 An2 0=V 1=mA Analog Input 2 enter – 0 for Voltage; 1 for Current
2 An3 0=V 1=mA Analog Input 3 enter – 0 for Voltage; 1 for Current
3 Unused
4 Unused
5 Unused
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
Speed Pot Minimum Voltage [Speed Pot Vmin]
Linear Number: 630
Default Value: 0.00 V
Minimum Value: -10.00 V
Maximum Value: 10.00 V
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the minimum output voltage from the speed potentiometer and is used for
calibrating the speed command.
