2-42 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Rated Motor Frequency [Rated Motor Freq]
Linear Number: 29
Default Value: 60 Hz
Minimum Value: 25 Hz
Maximum Value: 90 Hz
Access Level: Basic
Read/Write: Read/Write when Stopped
This parameter specifies the nameplate frequency corresponding to the parameter Rated Motor RPM.
This value could be different from the input frequency Rated Line Freq (17).
Rated Motor Horsepower [Rated Motor HP]
Linear Number: 25
Default Value: 1250 hp
Minimum Value: 10 hp
Maximum Value: 20000 hp
Access Level: Basic
Read/Write: Read/Write when Stopped
This parameter specifies the rated power of the motor in Imperial unit. This parameter and the Rated
Motor kW both specify the motor rating. If imperial unit is selected (default option) from Special Features
(99), then this parameter becomes the independent parameter while the Rated Motor kW will be
calculated by using the following relationship
1000
746
=
HPRatedMotor
kWRatedMotor
Rated Motor kW [Rated Motor kW]
Linear Number: 24
Default Value: 933 kW
Minimum Value: 10 kW
Maximum Value: 15000 kW
Access Level: Basic
Read/Write: Read/Write when Stopped
This parameter specifies the rated power of the motor in Metric unit. This parameter and the Rated Motor
HP both specify the motor rating. If Metric Units is selected from Special Features (99), then this
parameter becomes the independent parameter while the Rated Motor HP will be calculated by using the
following relationship
Rated Motor RPM [Rated Motor RPM]
Linear Number: 26
Default Value: 1192.0 RPM
Minimum Value: 150.0 RPM
Maximum Value: 3600.0 RPM
Access Level: Basic
Read/Write: Read/Write when Stopped
This parameter specifies the rated full load speed of the motor in RPM. It is equal to synchronous speed
for a synchronous motor and slightly less than synchronous speed for an induction motor.
