2-190 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Drive Application [Drv Application]
Linear Number: 751
Default Value: ID Fan
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the application in which the drive is being used and in intended for future use only.
Internal
Value
Enum Text Description
0 ID Fan Drive is running Induced Draft Fan
1 Pump 1 Drive is running Pump type 1
2 Pump 2 Drive is running Pump type 2
3 Conveyor Drive is running a conveyor
4 Compressor Drive is running a compressor
5 BanburyMixer Drive is running a Banbury Mixer
6 Application1 Future use
7 Application2 Future use
8 Application3 Future use
9 Application4 Future use
10 Application5 Future use
11 Application6 Future use
12 TestBay Dyn1 Drive under test is using Dyne 1
13 TestBay Dyn2 Drive under test is using Dyne 2
14 TestBay Dyn3 Drive under test is using Dyne 3
15 TestBay Dyn4 Drive under test is using Dyne 4
Contact factory for availability.
Process Control Parameters
Contact factory for availability.
PID Output [PID Output]
Linear Number: 356
Minimum Value: -2.0000 pu
Maximum Value: 2.0000 pu
Access Level: Advanced
Read/Write: Read Only
This parameter displays the final output of the PID controller in per unit. This is the sum of proportional,
integral, derivative and previous value of the PID Output. This value corresponds
to the Speed Command PID to drive.
Process Variable [Process Variable]
Linear Number: 357
Minimum Value: -2.0000 pu
Maximum Value: 2.0000 pu
Access Level: Advanced
Read/Write: Read Only
This parameter represents the feedback from process. This value is compared with Process Setpoint
(360) to calculate the error.
