2-164 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Logix XIO Register B [Logix Register B]
Linear Number: 715
Default Value: 0
Minimum Value: 0
Maximum Value: 65535
Access Level: Service
Read/Write: Read/Write
This parameter is reserved for future-use only, and represents a register within the drive that will have the
ability to be written to remotely. There is no code in the firmware utilizing this register.
Metering Parameters
Motor Speed Hz [Motor Speed Hz]
Linear Number: 487
Minimum Value: -120.0 Hz
Maximum Value: 120.0 Hz
Access Level: Basic
Read/Write: Read Only
This parameter displays the measured motor speed in Hz.
Motor Speed in RPM [Motor Speed RPM]
Linear Number: 363
Minimum Value: -4500 RPM
Maximum Value: 4500 RPM
Access Level: Basic
Read/Write: Read Only
This parameter is the measured rotor speed in RPM. It is used by the programming terminal and can also
be assigned to analog output to drive an optional analog meter.
Motor Current [Motor Current]
Linear Number: 361
Minimum Value: 0 A
Maximum Value: 1500 A
Access Level: Basic
Read/Write: Read Only
This parameter is the measured RMS value of the motor current. It is used by the programming terminal
and can also be assigned to analog output to drive an optional analog meter.
Motor Voltage [Motor Voltage]
Linear Number: 362
Minimum Value: 0 V
Maximum Value: 8000 V
Access Level: Basic
Read/Write: Read Only
This parameter is the measured RMS motor terminal voltage (line to line). It is used by the programming
terminal and can also be assigned to analog output to drive an optional analog meter.
