Rockwell Automation PowerFlex 7000 Technical Data

Parameters Listed by Linear Number 2-219
7000-TD002A-EN-P – September 2007
Parameters Listed by Linear Number
Name Min. Max. Default Units
Read-
Only
Access
1 Input Ctctr Cfg - - All Faults N Basic
3 Auto Restart Dly 0.0 10.0 0.0 sec N Basic
4 Operating Mode - - Normal N Monitor
5 Output Ctctr Cfg - - Not Running N Basic
7 Speed Ref Select - - Local N Monitor
8 Drv Fault6 Mask - - 1111111111111111 N Service
9 Drive Fault6 - - - Y Service
10 InpCtctr OpenDly 0.0 60.0 0.0 min N Advanced
11 Passcode 0 0 65535 - Y Monitor
12 Passcode 1 0 65535 - Y Monitor
13 Setup Wizard - - 0000000000000000 N Service
14 Liquid Outputs - - - Y Service
15 Line Cap kVAR 1 7500 400 kvar N Service
16 Line Cap Volts 100 10000 4160 V N Service
17 Rated Line Freq 50 60 60 Hz N Service
18 Rated Line Volts 100 7200 4160 V N Service
19 Rated Drive Amps 10 1750 159 A N Service
20 Motor Cap kVAR 1 7500 400 kvar N Service
21 Motor Cap Volts 100 10000 4160 V N Service
22 Rated Motor Volt 100 8000 4000 V N Basic
23 Rated Motor Amps 10 1500 159 A N Basic
24 Rated Motor kW 10 15000 933 kW N Basic
25 Rated Motor HP 10 20000 1250 hp N Basic
26 Rated Motor RPM 150.0 3600.0 1192.0 RPM N Basic
27 DCLnk Inductance 1.0 500.0 24.0 mH N Service
28 Motor Cap Freq 50 90 60 Hz N Service
29 Rated Motor Freq 25 90 60 Hz N Basic
30 Motor Type - - Induction N Service
31 Service Factor 0.75 1.25 1.00 N Basic
32 Line Cap Freq 50 60 60 Hz N Service
33 Preset Speed 1 0.5 75.0 30.0 Hz N Advanced
34 Preset Speed 2 0.5 75.0 35.0 Hz N Advanced
35 Preset Speed 3 0.5 75.0 40.0 Hz N Advanced
36 Profile Mask - - 11111111 N Basic
37 Profile Owner - - - Y Monitor
38 Passcode 2 0 65535 - Y Monitor
39 Passcode 3 0 65535 - Y Monitor
40 Preset Jog Speed 1.0 60.0 6.0 Hz N Basic
41 RefCmd Pot Min -120.0 120.0 6.0 Hz N Basic
42 RefCmd Pot Max 0.0 120.0 60.0 Hz N Basic
43 RefCmdAnlgInpMin -120.0 120.0 6.0 Hz N Basic
44 RefCmdAnlgInpMax 0.0 120.0 60.0 Hz N Basic
45 RefCmd DPI Min 0.0 120.0 6.0 Hz N Basic
46 RefCmd DPI Max 0.0 120.0 60.0 Hz N Basic
47 SpdCmd Pot -120.0 120.0 - Hz Y Basic
48 SpdCmd Anlg Inp1 -120.0 120.0 - Hz Y Basic
49 Skip Speed 1 1.0 90.0 90.0 Hz N Advanced
50 Skip Speed 2 1.0 90.0 90.0 Hz N Advanced
51 Skip Speed 3 1.0 90.0 90.0 Hz N Advanced
52 Liquid Inputs - - - Y Service
