2-220 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
53 Skip Speed Band1 0.0 5.0 0.0 Hz N Advanced
54 Skip Speed Band2 0.0 5.0 0.0 Hz N Advanced
55 Skip Speed Band3 0.0 5.0 0.0 Hz N Advanced
56 SpdCmd Anlg Inp2 -120.0 120.0 - Hz Y Basic
57 Field Current -2.000 2.000 - pu Y Service
58 SpdCmd DPI -120.0 120.0 - Hz Y Basic
59 SpdCmd PID -120.0 120.0 - Hz Y Basic
60 Coast Speed 1.0 100.0 2.0 Hz N Basic
61 Total Accel Time 0.0 1200.0 32.0 sec N Monitor
62 Total Decel Time 0.0 1200.0 32.0 sec N Monitor
63 Inertia Type - - Low N Basic
64 XIO Liquid Cool - - Unassigned N Advanced
65 Accel Time 1 0.0 1200.0 5.0 sec N Advanced
66 Accel Time 2 0.0 1200.0 3.0 sec N Advanced
67 Accel Time 3 0.0 1200.0 14.0 sec N Advanced
68 Accel Time 4 0.0 1200.0 10.0 sec N Advanced
69 Decel Time 1 0.0 1200.0 5.0 sec N Advanced
70 Decel Time 2 0.0 1200.0 3.0 sec N Advanced
71 Decel Time 3 0.0 1200.0 14.0 sec N Advanced
72 Decel Time 4 0.0 1200.0 10.0 sec N Advanced
73 Ramp Speed 1 5.0 100.0 5.0 Hz N Advanced
74 Ramp Speed 2 5.0 100.0 12.0 Hz N Advanced
75 Ramp Speed 3 5.0 100.0 54.0 Hz N Advanced
76 Ramp Speed 4 5.0 100.0 60.0 Hz N Advanced
77 Control AC#2 RMS 0.0 300.0 - V Y Advanced
78 Motor Flux Time 0.0 10.0 3.0 sec N Advanced
79 Control AC#3 RMS 0.0 300.0 - V Y Advanced
80 Ramp Test Step 0.0 30.0 0.0 Hz N Service
81 SpdReg Bandwidth 0.1 15.0 1.0 r/s N Advanced
82 Total Inertia 0.10 50.00 1.00 sec N Advanced
84 Trq Lmt Motoring 0.00 4.00 1.05 N Advanced
85 Trq Lmt Braking 0.00 4.00 0.50 N Advanced
86 TrqCmd0 SensrLss 0.00 4.00 0.40 N Advanced
87 TrqCmd1 SensrLss 0.00 4.00 0.40 N Advanced
88 Speed Ref Step 0.0 2.0 0.0 Hz N Service
89 Speed Fbk Mode - - Sensorless N Advanced
90 Trq Control Mode - - Speed Reg N Advanced
91 Trq Cmd External -4.000 4.000 0.000 N Advanced
92 Control AC#4 RMS 0.0 300.0 - V Y Advanced
93 DPI Loss Fault - - - Y Service
94 Logic Owner - - - Y Monitor
95 Rec Pulse Number 0 36 - Y Service
96 InvAnlg SelfTst1 - - - Y Service
97 FlxReg Bandwidth 1.0 30.0 10.0 r/s N Advanced
98 Base Speed 25.0 100.0 60.0 Hz N Service
99 Special Features - - 0000000000000000 N Advanced
100 FlxCmd RatedLoad 0.000 1.500 0.900 pu N Advanced
101 IGDPS 56V 0.0 72.0 - V Y Advanced
102 Flux RefStep 0.000 0.100 0.000 pu N Service
103 FlxCmd No Load 0.400 1.500 0.700 pu N Advanced
104 Ctrl Pwr FltMask - - 1111111111111111 N Basic
105 Ctrl Pwr WrnMask - - 1111111111111111 N Basic
106 Field Bandwidth 0.1 100.0 10.0 r/s N Advanced
107 Icd Command Gain 0.0 1.0 0.5 N Advanced
108 Line CurUnbalTrp 0.00 1.00 0.05 pu N Advanced
109 Line CurUnbalDly 0.0 10.0 1.0 sec N Advanced
