2-94 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Control Power Warning Mask [Ctrl Pwr WrnMask]
Linear Number: 105
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the warning mask for the various components used in protecting the control
power system feeding the drive. The following warnings are maskable:
Bit Enum Text Description
0 ACDC#1 Redn Redundant AC/DC#1 Supply Module failure Warning
1 ACDC#2 Redn Redundant AC/DC#1 Supply Module failure Warning
2 ACDC#3 Redn Redundant AC/DC#1 Supply Module failure Warning
3 ACDC#4 Redn Redundant AC/DC#1 Supply Module failure Warning
4 ACDC#1ACFail Loss of 120V AC Power to AC/DC#1 Power Supply
5 ACDC#2ACFail Loss of 120V AC Power to AC/DC#2 Power Supply
6 ACDC#3ACFail Loss of 120V AC Power to AC/DC#3 Power Supply
7 ACDC#4ACFail Loss of 120V AC Power to AC/DC#4 Power Supply
8 CtrlPwr Loss Loss of 120V AC Control Power
9 UPS onBypass UPS running on bypass
10 UPS on Batt UPS running on battery
11 UPS Batt Low UPS battery low
12 UPS Failed UPS has an internal failure
13 XIO Pwr Loss XIO power loss
14 Ctrl5V Redn Loss of Redundant 5V
15 Unused
DPI Loss Mask [DPI Loss Mask]
Linear Number: 175
Default Value: 0000000000000000
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the masks for detecting loss of individual DPI adapters. The default value for
this parameter enables a Warning for an adapter loss. Changing the corresponding bit to 1 will change
the drive response from Warning to Fault.
Bit Enum Text Description
0 Adapter1Loss Loss of Adapter 1
1 Adapter2Loss Loss of Adapter 2
2 Adapter3Loss Loss of Adapter 3
3 Adapter4Loss Loss of Adapter 4
4 Adapter5Loss Loss of Adapter 5
5 Adapter6Loss Loss of Adapter 6
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
