Parameter Descriptions 2-195
7000-TD002A-EN-P – September 2007
Slave 2 Bridge Phasing [Slave2 Phasing]
Linear Number: 665
Access Level: Service
Read/Write: Read Only
This parameter specifies the results obtained from phasing check for the Slave2 rectifier bridge on 18-
pulse drives.
Bit Enum Text Description
0 Required-ABC
1 Required-ACB
2 Required-BAC
3 Required-BCA
4 Required-CBA
5 Required-CAB
6
7
8 Actual-ABC
9 Actual-ACB
10 Actual-BAC
11 Actual-BCA
12 Actual-CBA
13 Actual-CAB
14
15
Commission Status [CommissionStatus]
Linear Number: 667
Access Level: Service
Read/Write: Read Only
This parameter displays the commissioning status.
Bit Enum Text Description
0 DIM Valid DIM validated
1 Drv Isolated Drive is Isolated
2 MV Present Medium voltage is present
3 PhasingDone Phasing check has been done
4 Unused
5 Unused
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
