2-152 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Optional XIO Outputs [OptXIO Output]
Linear Number: 427
Access Level: Advanced
Read/Write: Read Only
This parameter specifies the state of the outputs on the optional XIO card. There are 16 outputs
available. They are currently not assigned and reserved for future use only.
Bit Enum Text Description
0 Outbit 0
1 Outbit 1
2 Outbit 2
3 Outbit 3
4 Outbit 4
5 Outbit 5
6 Outbit 6
7 Outbit 7
8 Outbit 8
9 Outbit 9
10 Outbit 10
11 Outbit 11
12 Outbit 12
13 Outbit 13
14 Outbit 14
15 Outbit 15
Contact factory for availability.
Liquid Inputs [Liquid Inputs]
Linear Number: 52
Access Level: Service
Read/Write: Read Only
This parameter specifies the state of the inputs on the XIO card assigned for the Liquid Cooling System.
There are 16 inputs available, from External 1 to External 16. A one indicates that the specific input of
the card is active, and a zero means that specific input is missing.
Bit Enum Text Description
0 Pump Aux 1 Pump 1 Control Relay Auxiliary
1 Pump Aux 2 Pump 2 Control Relay Auxiliary
2 Fan Aux 1 Fan 1 Control Relay Auxiliary
3 Fan Aux 2 Fan 2 Control Relay Auxiliary
4 Fan Aux 3 Fan 3 Control Relay Auxiliary
5 Fan Aux 4 Fan 4 Control Relay Auxiliary
6 Unused
7 DC Link Flow DC Link Flow Measurement Switch Feedback
8 DisconnectSw The Cooling System Disconnect switch feedback
9 Low Pressure Cooling System Low Pressure Indication
10 Low Level Cooling System Low Level Warning Indication
11 Level Trip Cooling System Low Level Fault Indication
12 Cond High Cooling System Conductivity Warning Indication
13 Cond Trip Cooling System Conductivity Fault Indication
14 Pmp Select#1 Pump #1 has been selected as the active Pump
15 Pmp Select#2 Pump #2 has been selected as the active Pump
To Next Page
