2-108 Parameter Descriptions
7000-TD002A-EN-P – September 2007
External Fault PLC [Ext Fault PLC]
Linear Number: 650
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter specifies the external inputs coming from the PLC. The parameter External Fault Select
allows the user to choose whether the faults come from the XIO board, or from a PLC, or from a
combination of the 2 sources. These have been configured as faults (Class1 or Class2). A ‘1’ indicates
an active fault on the card or PLC. There are a total of 16 external faults from External1 to External16.
The user can modify the text associated with each fault.
Bit Enum Text Description
0 External1 External Fault 1
1 External2 External Fault 2
2 External3 External Fault 3
3 External4 External Fault 4
4 External5 External Fault 5
5 External6 External Fault 6
6 External7 External Fault 7
7 External8 External Fault 8
8 External9 External Fault 9
9 External10 External Fault 10
10 External11 External Fault 11
11 External12 External Fault 12
12 External13 External Fault 13
13 External14 External Fault 14
14 External15 External Fault 15
15 External16 External Fault 16
Liquid Cooling System Fault [Liquid Cool Flt]
Linear Number: 358
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter specifies the faults associated with liquid cooling system in ‘C Frame’ drives. A ‘1’
represents an active liquid cooling system fault. The following faults are displayed:
Bit Enum Text Description
0 PressureLoss Loss of System Pressure (not maskable)
1 ExtCool Loss Loss of External Cooling (Heat Exchanger Issue)
2 CoolTemp Low Coolant Temperature Low
3 CoolTempHigh Coolant Temperature High
4 Conduct Hi High Conductivity in the Coolant (not maskable)
5 CoolLevelLow Coolant Level Low
6 CabTempHigh Cabinet Temperature High
7 Pump/Fan Pwr Pump and Fan Power Off
8 DC Link Flow DC Link Flow
9 TempFbk Loss Loss of Coolant Temperature Feedback
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
