2-34 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Rated Drive Amps [Rated Drive Amps]
Linear Number: 19
Default Value: 159 A
Minimum Value: 10 A
Maximum Value: 1750 A
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the maximum continuous RMS current rating of the drive. This should be
obtained from the dimensional drawing or the drive nameplate.
Rated Line Frequency [Rated Line Freq]
Linear Number: 17
Default Value: 60 Hz
Minimum Value: 50 Hz
Maximum Value: 60 Hz
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the rated input line frequency of the drive, and must be set to either 50Hz or 60Hz.
Rated Line Voltage [Rated Line Volts]
Linear Number: 18
Default Value: 4160 V
Minimum Value: 100 V
Maximum Value: 7200 V
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the rated input line voltage fed to the drive. It is used for normalizing the line
voltage calculations and also used in determining the voltage tap and the voltage gain.
Rectifier Type [Rectifier Type]
Linear Number: 153
Default Value: 6 PWM
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the power circuit topology of the rectifier used in the drive design. PF7000
currently provides three different rectifier configurations:
6 PWM This parameter selects control for a 6-pulse PWM rectifier.
6 SCR This parameter selects control for a 6-pulse SCR rectifier.
18 SCR This parameter selects control for an 18-pulse SCR rectifier.
12 SCR This parameter selects control for a 12-pulse SCR rectifier
Contact factory for availability
