Parameter Descriptions 2-153
7000-TD002A-EN-P – September 2007
Liquid Outputs [Liquid Outputs]
Linear Number: 14
Access Level: Service
Read/Write: Read Only
This parameter specifies the state of the outputs on the XIO card assigned for the Liquid Cooling System.
There are 16 outputs available, from External 1 to External 16. A one indicates that the specific output of
the card is closed.
Bit Enum Text Description
0 Pump Ctctr 1 Pump Contactor 1 output is active
1 Pump Ctctr 2 Pump Contactor 2 output is active
2 Fan Ctctr 1 Fan Contactor 1 output is active
3 Fan Ctctr 2 Fan Contactor 2 output is active
4 Fan Ctctr 3 Fan Contactor 3 output is active
5 Fan Ctctr 4 Fan Contactor 4 output is active
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
Logix Inputs [Logix Inputs]
Linear Number: 687
Access Level: Service
Read/Write: Read Only
This parameter represents the inputs on the optional Logix IO XIO board.
Bit Enum Text Description
0 Input #1 Input #1
1 Input #2 Input #2
2 Input #3 Input #3
3 Input #4 Input #4
4 Input #5 Input #5
5 Input #6 Input #6
6 Input #7 Input #7
7 Input #8 Input #8
8 Input #9 Input #9
9 Input #10 Input #10
10 Input #11 Input #11
11 Input #12 Input #12
12 Input #13 Input #13
13 Input #14 Input #14
14 Input #15 Input #15
15 Input #16 Input #16
