2-98 Parameter Descriptions
7000-TD002A-EN-P – September 2007
External Warning [External Warning]
Linear Number: 429
Access Level: Service
Read/Write: Read Only
This parameter specifies those inputs on the optional XIO card, which have been configured as warnings.
A ‘1’ indicates an active warning on the card. There are a total of 16 external warnings from External1 to
External16. The user can modify the text associated with each warning.
Bit Enum Text Description
0 External1 External Warning 1
1 External2 External Warning 2
2 External3 External Warning 3
3 External4 External Warning 4
4 External5 External Warning 5
5 External6 External Warning 6
6 External7 External Warning 7
7 External8 External Warning 8
8 External9 External Warning 9
9 External10 External Warning 10
10 External11 External Warning 11
11 External12 External Warning 12
12 External13 External Warning 13
13 External14 External Warning 14
14 External15 External Warning 15
15 External16 External Warning 16
Drive Fault Word 1 [Drive Fault1]
Linear Number: 279
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the first fault word corresponding to drive protection.
These faults can be either Class 1 or Class 2 faults. A ‘1’ represents an active fault as follows:
Bit Enum Text Description
0 Line OvrCur Line Over Current
1 DCLnkOvrCur DC Link Over Current Fault
2 Gnd OvrCur Ground Fault Over Current Fault
3 RNeut OvrCur Neutral Resistor Over Current Fault
4 Line OvrVolt Line Over Voltage
5 Rec OvrVolt Rectifier Over Voltage Fault
6 LineNeuOvVol Line to Neutral Over Voltage Fault
7 LineHarmonic Line Harmonic Fault
8 MstrVolUnBal Master Bridge Line Voltage Unbalance
9 Slv1VolUnBal Slave1 Bridge Line Voltage Unbalance
10 Slv2VolUnBal Slave2 Bridge Line Voltage Unbalance
11 MstrCurUnBal Master Bridge Line Current Unbalance
12 Slv1CurUnBal Slave1 Bridge Line Current Unbalance
13 Slv2CurUnBal Slave2 Bridge Line Current Unbalance
14 Slv1 Phasing Slave1 bridge phasing fault
15 Slv2 Phasing Slave2 bridge phasing fault
