Rockwell Automation PowerFlex 7000 Technical Data

Parameter Descriptions 2-99
7000-TD002A-EN-P – September 2007
Drive Fault Word 2 [Drive Fault2]
Linear Number: 280
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the second fault word corresponding to drive protection.
These faults can be either Class 1 or Class 2. A ‘1’ represents an active fault as follows:
Bit Enum Text Description
0 RecAnaSlfTst Rectifier Self analog Test Fail
1 RecFbrOptCfg Rectifier Fiber Optic Cable Configuration Fault
2 Unused
3 Rec A2D Conv Rectifier A2D Converter Fault
4 InvHeartbeat Inverter Heartbeat Fault
5 Unused
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
Drive Fault Word 3 [Drive Fault3]
Linear Number: 281
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the third fault word corresponding to drive protection.
These faults can be either Class 1 or Class 2. A ‘1’ represents an active fault as follows:
Bit Enum Text Description
0 Drv OvrLoad Drive Overload fault
1 RNeutOvrLoad Line Neutral to Ground Overvoltage fault
2 RecHSnkOvTmp Rectifier Heatsink Over Temperature fault
3 RecHSnkLoTmp Rectifier Heatsink Low Temperature Fault
4 RecHSnkFbrOp Rectifier Heatsink Fiber Optic Cable
5 RecHSnk Sens Rectifier Heatsink Sensor Disconnected Fault
6 RecChB OvTmp Rectifier Channel B Over Temperature fault
7 RecChB LoTmp Rectifier Channel B Low Temperature fault
8 RecChB FbrOp Rectifier Heatsink Channel B Fiber Optic Cable
9 RecChB Sens Rectifier Channel B Sensor Disconnected Fault
10 Dvc AK/Snubb Device Anode Cathode or Snubber fault
11 Current Sens Current Sensor Fault
12 Unused
13 Unused
14 Unused
15 Unused
