Rockwell Automation PowerFlex 7000 Technical Data

2-144 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Analog Input3 Minimum Voltage [Anlg Inp3 Vmin]
Linear Number: 636
Default Value: 0.00 V
Minimum Value: -10.00 V
Maximum Value: 10.00 V
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the minimum voltage which can be used on Analog Input 3 and is used for
calibrating the speed command.
Analog Input3 Maximum Voltage [Anlg Inp3 Vmax]
Linear Number: 637
Default Value: 10.00 V
Minimum Value: -10.00 V
Maximum Value: 10.00 V
Access Level: Service
Read/Write: Read/Write when Stopped
This parameter specifies the maximum voltage which can be used on Analog Input 3 and is used for
calibrating the speed command.
Analog Outputs Parameters
Analog Meter 1 [Anlg Meter1]
Linear Number: 517
Default Value: 361
Minimum Value: 0
Maximum Value: 779
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the linear number of the parameter associated with analog meter 1 on the
Analog Control Board (ACB). The meter output is scalable using AnlgMeter1 Scale (521). This is a non-
isolated 0-10 V output. The default value of 361 corresponds to the Motor Current parameter.
Analog Meter 2 [Anlg Meter2]
Linear Number: 518
Default Value: 362
Minimum Value: 0
Maximum Value: 779
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the linear number of the parameter associated with analog meter 2 on the
Analog Control Board (ACB). The meter output is scalable using AnlgMeter2 Scale (522). This is a non-
isolated 0-10 V output. The default value of 362 corresponds to the Motor Voltage parameter.
