Rockwell Automation PowerFlex 7000 Technical Data

Parameter Descriptions 2-197
7000-TD002A-EN-P – September 2007
Full Scale Reference [Scale Full Ref]
Linear Number: 660
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
his parameter is used for calibration of analog inputs in the drive and prompts the user to enter the full
scale reference value for the particular input.
Bit Enum Text Description
0 Speed Pot
1 Anlg Input1
2 Anlg Input2
3 Anlg Input3
4 Convrter AirFlow
5 IsoTx AirFlow
6
7
8
9
10
11
12
13
14
15
Provide Zero Reference [Provide Zero Ref]
Linear Number: 661
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter is used for calibration of analog outputs in the drive and prompts the drive to output the
zero scale reference value for the particular output.
Bit Enum Text Description
0 Anlg Meter1
1 Anlg Meter2
2 Anlg Meter3
3 Anlg Meter4
4 Anlg Output1
5 Anlg Output2
6 Anlg Output3
7 Anlg Output4
8 Anlg 4-20mA
9
10
11
12
13
14
15
