2-198 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Provide Full Scale Reference [Provide Full Ref]
Linear Number: 662
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter is used for calibration of analog outputs in the drive and prompts the drive to output the
full scale reference value for the particular output.
Bit Enum Text Description
0 Anlg Meter1
1 Anlg Meter2
2 Anlg Meter3
3 Anlg Meter4
4 Anlg Output1
5 Anlg Output2
6 Anlg Output3
7 Anlg Output4
8 Anlg 4-20mA
9
10
11
12
13
14
15
Setup Wizard [Setup Wizard]
Linear Number: 13
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter specifies the progress of the Setup Wizard. A ‘1’ indicates that the step has been
completed by the setup wizard. Until all the steps are completed, you will always be prompted to continue
with the process each time control power is cycled. The following steps are displayed:
Bit Enum Text Description
0 Path Picked For Internal use only
1 Gating Test Perform gating checks on the drive
2 Motor Data Enter motor nameplate data
3 Features Enter Feature Select parameters
4 Speed Ref Enter Speed Profile parameters
5 Analog Calib Calibrate analog system
6 Ext Faults Configure the External Faults
7 System Test Perform System Test
8 Phasing Chck Performed phasing check for an 18-pulse drive
9 Autotuning Autotune drive and motor parameters
10 DC Test Run the drive in DC Current Test Mode
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
