2-194 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Commissioning Parameters
Contact factory for availability.
Master Bridge Phasing [Master Phasing]
Linear Number: 663
Access Level: Service
Read/Write: Read Only
This parameter specifies the results obtained from phasing check for the Master rectifier bridge.
Bit Enum Text Description
0 Required-ABC
1 Required-ACB
2 Required-BAC
3 Required-BCA
4 Required-CBA
5 Required-CAB
6
7
8 Actual-ABC
9 Actual-ACB
10 Actual-BAC
11 Actual-BCA
12 Actual-CBA
13 Actual-CAB
14
15
Slave 1 Bridge Phasing [Slave1 Phasing]
Linear Number: 664
Access Level: Service
Read/Write: Read Only
This parameter specifies the results obtained from phasing check for the Slave1 rectifier bridge on
18-pulse drives.
Bit Enum Text Description
0 Required-ABC
1 Required-ACB
2 Required-BAC
3 Required-BCA
4 Required-CBA
5 Required-CAB
6
7
8 Actual-ABC
9 Actual-ACB
10 Actual-BAC
11 Actual-BCA
12 Actual-CBA
13 Actual-CAB
14
15
