2-154 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Logix Outputs [Logix Outputs]
Linear Number: 688
Access Level: Service
Read/Write: Read Only
This parameter represents the outputs on the optional Logix IO XIO board.
Bit Enum Text Description
0 Output#1 Output#1
1 Output#2 Output#2
2 Output#3 Output#3
3 Output#4 Output#4
4 Output#5 Output#5
5 Output#6 Output#6
6 Output#7 Output#7
7 Output#8 Output#8
8 Output#9 Output#9
9 Output#10 Output#10
10 Output#11 Output#11
11 Output#12 Output#12
12 Output#13 Output#13
13 Output#14 Output#14
14 Output#15 Output#15
15 Output#16 Output#16
XIO Configuration Errors [XIO Config Errs]
Linear Number: 594
Access Level: Advanced
Read/Write: Read Only
This parameter specifies the error in the XIO configuration. A one represents an indicated error, a zero
represents no error. The error results from the same slot being assigned to two or more XIO boards, or
when the board is not installed in the assigned slot. The following error messages are displayed:
Bit Enum Text Description
0 Stnd IO Cnfg Standard XIO configuration error
1 Stnd IO Cnft Standard XIO conflict error
2 Ext Flt Cnfg External/Optional XIO configuration error
3 Ext Flt Cnft External/Optional XIO conflict error
4 Liqd IO Cnfg Liquid-Cooled XIO configuration error
5 Liqd IO Cnft Liquid-Cooled XIO conflict error
6 LogixIO Cnfg Logix XIO configuration error
7 LogixIO Cnft Logix XIO conflict error
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
