Parameter Descriptions 2-55
7000-TD002A-EN-P – September 2007
D-Axis Magnetizing Inductance [Lmd]
Linear Number: 418
Default Value: 1.00 pu
Minimum Value: 0.10 pu
Maximum Value: 10.00 pu
Access Level: Advanced
Read/Write: Read/Write
This parameter specifies the d-axis magnetizing inductance for synchronous motors. It can be set
manually or by auto-tuning. This parameter is not used for induction motors.
Contact factory for availability
Q-Axis Torque Inductance [Lmq]
Linear Number: 296
Default Value: 1.00 pu
Minimum Value: 0.10 pu
Maximum Value: 10.00 pu
Access Level: Advanced
Read/Write: Read/Write
This parameter specifies the q-axis torque inductance for synchronous motors. It can be set manually or
by auto-tuning. This parameter is not used for induction motors.
Speed Command Parameters
Speed Command [Speed Command]
Linear Number: 277
Minimum Value: -120.0 Hz
Maximum Value: 120.0 Hz
Access Level: Basic
Read/Write: Read Only
This parameter is the drive speed command, which is the input to the speed ramp. It is set to zero when
the drive is not running.
Speed Command Input [Speed Command In]
Linear Number: 276
Minimum Value: -120.0 Hz
Maximum Value: 120.0 Hz
Access Level: Basic
Read/Write: Read Only
This parameter is the value of the selected speed command input. It is valid whether the drive is running
or not.
Control Reference [Control Refernce]
Linear Number: 275
Minimum Value: 0.0 Hz
Maximum Value: 6553.5 Hz
Access Level: Basic
Read/Write: Read Only
This parameter specifies the control reference value used by the drive regulators. This value is selected
from a local, remote or digital reference command as indicated by the parameter Speed Ref Select (7).
