Parameter Descriptions 2-107
7000-TD002A-EN-P – September 2007
Adapter Loss Warning [DPI Loss Warning]
Linear Number: 148
Access Level: Service
Read/Write: Read Only
This parameter specifies the DPI adapter loss warning. DPI is a polled communication network and if
that link is lost, the associated warning will occur. A ‘1’ represents an active warning.
Bit Enum Text Description
0 Adapter1Loss Adapter 1 Loss Warning
1 Adapter2Loss Adapter 2 Loss Warning
2 Adapter3Loss Adapter 3 Loss Warning
3 Adapter4Loss Adapter 4 Loss Warning
4 Adapter5Loss Adapter 5 Loss Warning
5 Adapter6Loss Adapter 6 Loss Warning
6 Spd Cmd Loss Speed Command Loss Warning
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
XIO Adapter Loss [XIO Adaptr Loss]
Linear Number: 596
Access Level: Service
Read/Write: Read Only
This parameter specifies the XIO adapter loss. There are 6 possible XIO slots, from Slot 1 to Slot 6. ‘1’
means the adapter is lost, ‘0’ means the adapter is still active if installed in the drive.
Bit Enum Text Description
0 XIO Card #1 Loss of XIO Board connected to Slot #1
1 XIO Card #2 Loss of XIO Board connected to Slot #2
2 XIO Card #3 Loss of XIO Board connected to Slot #3
3 XIO Card #4 Loss of XIO Board connected to Slot #4
4 XIO Card #5 Loss of XIO Board connected to Slot #5
5 XIO Card #6 Loss of XIO Board connected to Slot #6
6 Unused
7 Unused
