Parameter Descriptions 2-177

7000-TD002A-EN-P – September 2007

Write Mask Configuration [Write Mask Cfg]

Linear Number: 711

Default Value: 0000000001111111

Access Level: Advanced

Read/Write: Read/Write

This parameter allows user to program the Write Mask Active attribute when power is cycled to the drive.

Bit Enum Text Description

0 Host

1 DPI Port1

2 DPI Port2

3 DPI Port3

4 DPI Port4

5 DPI Port5

6 DPI Port6

7 Reserved

8 Reserved

9 Reserved

10 Reserved

11 Reserved

12 Reserved

13 Reserved

14 Reserved

15 Advanced

Write Mask Act [Write Mask Act]

Linear Number: 712

Access Level: Advanced

Read/Write: Read Only

This parameter provides read-only access to the current value of the write Mask Active attribute for

diagnostic purposes. When bit 15 is set, it indicates that FactoryTalk security or some other Advanced

Security tool has set the Write Mask Active attribute. Each bit in the parameter controls whether the

device attached to the DPI port can write to parameters or links.
