Parameter Descriptions 2-129
7000-TD002A-EN-P – September 2007
Control Masks Parameters
Direction Command Mask [Direction Mask]
Linear Number: 244
Default Value: 11111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies which adapters can issue the forward/reverse command. A one represents the
adapter that can issue the direction command, a zero represents an adapter that cannot issue the
direction command. There are 8 adapters available, from Adapter0 to Adapter7. Adapter 0 is the XIO
board, Adapter 7 is the programming terminal, and Adapter 1 to Adapter 6 are the DPI adapters.
Bit Enum Text Description
0 Adapter 0 Host
1 Adapter 1
2 Adapter 2
3 Adapter 3 (Currently unused)
4 Adapter 4 (Currently unused)
5 Adapter 5
6 Adapter 6 (Currently unused)
7 Adapter 7 (Currently unused)
Jog Command Mask [Jog Mask]
Linear Number: 245
Default Value: 11111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies which adapters can issue the jog command. A one represents the adapter that
can issue the jog command, a zero represents an adapter that cannot issue the jog command. There are
8 adapters available, from Adapter0 to Adapter7.
Bit Enum Text Description
0 Adapter 0 Host
1 Adapter 1
2 Adapter 2
3 Adapter 3 (Currently unused)
4 Adapter 4 (Currently unused)
5 Adapter 5
6 Adapter 6 (Currently unused)
7 Adapter 7 (Currently unused)
