2-180 Parameter Descriptions
7000-TD002A-EN-P – September 2007
PD Flags [PD Flags]
Linear Number: 722
Default Value: 0000000000000000
Access Level: Service
Read/Write: Read/Write
This parameter is the parallel drive flag word. Four bits are defined:
Bit Enum Text Description
0 Node Reset Node Reset, set to clear parallel drives faults and warnings reset
automatically after faults cleared
1 Active Mstr Active Master- this drive is the current master
2 Pass Mastr Pass Master- this drive is attempting to pass mastership
3 Pass Mstr En Pass Master Enabled-Pass Master is allowed for this drive
4 Unused
5 Unused
6 Unused
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
PD Fault Word [PD Fault Word]
Linear Number: 720
Access Level: Advanced
Read/Write: Read Only
This is the parallel drive fault word.
Bit Enum Text Description
0 Comm Timeout Drive has lost communications with the master
1 Mstr Xfer Er Master Transfer Error
2 Unused
3 Unused
4 Unused
5 Unused
6 Unused
7 Unused
8 Slave 0 Comm Master has lost communication with Drive 0
9 Slave 1 Comm Master has lost communication with Drive 1
10 Slave 2 Comm Master has lost communication with Drive 2
11 Slave 3 Comm Master has lost communication with Drive 3
12 Slave 4 Comm Master has lost communication with Drive 4
13 Slave 5 Comm Master has lost communication with Drive 5
14 Slave 6 Comm Master has lost communication with Drive 6
15 Slave 7 Comm Master has lost communication with Drive 7
