Rockwell Automation PowerFlex 7000 Technical Data

2-82 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Standard XIO Fault Mask [Stnd XIOFlt Mask]
Linear Number: 435
Default Value: 11111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies if the alarm is set to trigger a Warning/Fault. A ‘1’ represents enabled fault, a ‘0’
represents disabled fault. The following faults are maskable:
Bit Enum Text Description
0 Input Protn1 Input Protection 1 fault
1 TxReacOvrTmp Isolation Transformer/Line Reactor Over temperature fault
2 DCLinkOvrTmp DC Link / Common-Mode Choke Over temperature fault
3 Motor Protn Motor Protection fault
4 Input Protn2 Input Protection 2 fault
5 Aux Protn Auxiliary Protection fault
6 Unused
7 Unused
External Fault Select [Ext Fault Selct]
Linear Number: 651
Default Value: 0000000000000000
Access Level: Basic
Read/Write: Read/Write
This parameter specifies whether the external fault inputs are coming from the optional XIO card or the
PLC. The parameter allows the user to choose whether the faults come from the XIO board, or from a
PLC, or from a combination of the 2 sources. By setting the bit to a 1, the associated external fault
comes from the PLC. Setting the bit to a zero allows the external fault to come from the XIO board.
External Fault 1 Class [ExtFault1 Class]
Linear Number: 200
Default Value: Class2 Fault
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the class of the external fault 1. This is applicable only if the optional XIO board
is installed. The following options are available:
Disable This disables the fault input.
Class1 Fault The drive will shut down immediately
Class2 Fault The drive will perform a controlled shut down
Warning The drive will not shut down but a warning will be displayed
External Fault 2 Class [ExtFault2 Class]
Linear Number: 201
Default Value: Class2 Fault
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the class of the external fault 2. This is applicable only if the optional XIO board
is installed. The following options are available:
Disable This disables the fault input.
Class1 Fault The drive will shut down immediately
Class2 Fault The drive will perform a controlled shut down
Warning The drive will not shut down but a warning will be displayed
