2-106 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Control Power Warning [Ctrl Pwr Warning]
Linear Number: 288
Access Level: Service
Read/Write: Read Only
This parameter specifies which of the various components used in protecting the control power system
feeding the drive are issuing a warning. A ‘1’ indicates an active warning.
Bit Enum Text Description
0 ACDC#1 Redn Loss of AC/DC#1 Redundant Power Supply
1 ACDC#2 Redn Loss of AC/DC#2 Redundant Power Supply
2 ACDC#3 Redn Loss of AC/DC#3 Redundant Power Supply
3 ACDC#4 Redn Loss of AC/DC#4 Redundant Power Supply
4 ACDC#1ACFail Loss of 120V AC to AC/DC#1 Power Supply
5 ACDC#2ACFail Loss of 120V AC to AC/DC#2 Power Supply
6 ACDC#3ACFail Loss of 120V AC to AC/DC#3 Power Supply
7 ACDC#4ACFail Loss of 120V AC to AC/DC#4 Power Supply
8 CtrlPwr Loss Loss of 120V AC Control Power to AC/DC Power Supply
9 UPS onBypass UPS running on bypass
10 UPS on Batt UPS running on battery
11 UPS Batt Low UPS battery low
12 UPS Failed UPS has an internal failure
13 XIO Pwr Loss XIO power loss
14 Ctrl5V Redn Loss of Redundant 5V to DPM
15 Unused
DPI Loss Fault [DPI Loss Fault]
Linear Number: 93
Access Level: Service
Read/Write: Read Only
This parameter specifies the DPI adapter loss fault. DPI is a polled communication network and if that
link is lost, the associated fault will occur. A ‘1’ represents an active fault.
Bit Enum Text Description
0 Adapter 1 Adapter 1 Loss Fault
1 Adapter 2 Adapter 2 Loss Fault
2 Adapter 3 Adapter 3 Loss Fault
3 Adapter 4 Adapter 4 Loss Fault
4 Adapter 5 Adapter 5 Loss Fault
5 Adapter 6 Adapter 6 Loss Fault
6 Spd Cmd Loss Speed Command Loss Fault
7 Unused
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
