Parameter Descriptions 2-105
7000-TD002A-EN-P – September 2007
PD Warning Flag [PD Warning]
Linear Number: 758
Access Level: Service
Read/Write: Read Only
These are the parallel drive warning flags.
Bit Enum Text Description
0 Hub Comm Wrn Hub (PLC) Communications Loss
1 Duplcte Mstr Duplicate Master-master only
2 Dclnd Mstr Slave Declined Master-slave only
3 Slv RfsdMstr Slave Refused Master-master only
4 InvldMstrReq Invalid Master Request-slave only
5 Xfer Disable Transfer Disabled-master only
6 Unused
7 Unused
8 Slave 0 Comm Slave 0 DAN Communications Loss-master only
9 Slave 1 Comm Slave 1 DAN Communications Loss-master only
10 Slave 2 Comm Slave 2 DAN Communications Loss-master only
11 Slave 3 Comm Slave 3 DAN Communications Loss-master only
12 Slave 4 Comm Slave 4 DAN Communications Loss-master only
13 Slave 5 Comm Slave 5 DAN Communications Loss-master only
14 Slave 6 Comm Slave 6 DAN Communications Loss-master only
15 Slave 7 Comm Slave 7 DAN Communications Loss-master only
Control Power Fault [Ctrl Pwr Fault]
Linear Number: 287
Access Level: Service
Read/Write: Read Only
This parameter specifies which of the various components used in protecting the control power system
feeding the drive have faulted. A ‘1’ indicates an active fault.
Bit Enum Text Description
0 ACDC#1DCFail AC/DC#1 56V DC Output Loss Fault
1 ACDC#2DCFail AC/DC#2 56V DC Output Loss Fault
2 ACDC#3DCFail AC/DC#3 56V DC Output Loss Fault
3 ACDC#4DCFail AC/DC#4 56V DC Output Loss Fault
4 Ctrl56V Loss Control Power 56V Loss Fault
5 IGDPS56VLoss IGDPS 56V Loss Fault
6 Ctrl5V Loss Loss of Non-Redundant 5V to DPM
7 Ctrl15V Loss Loss of Non-Redundant 15V to ACB
8 HECS PwrLoss HECS Connector Power Loss
9 Ctrl PwrLoss Loss of 120V AC Power to AC/DC
10 ACDC#1ACFail AC/DC#1 120V AC Loss Fault
11 ACDC#2ACFail AC/DC#2 120V AC Loss Fault
12 ACDC#3ACFail AC/DC#3 120V AC Loss Fault
13 ACDC#4ACFail AC/DC#4 120V AC Loss Fault
14 UPS Fault UPS Faulted
15 Isol24V Loss Isolator 24V Loss
