Rockwell Automation PowerFlex 7000 Technical Data

2-104 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Drive Warning Word 5 [Drive Warning5]
Linear Number: 706
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the fifth warning word corresponding to drive fault
detection. A ‘1’ represents an active warning as follows:
Bit Enum Text Description
0 InvHSnkOvTmp Inverter Heat Sink Over Temperature Warning
1 Amb OvTmp Ambient Over Temperature Warning
2 InvHSnk Sens Inverter Heat Sink Sensor Warning
3 Amb Sens Ambient Sensor Warning
4 InvHSnkFbrOp Inverter Heat Sink Fiber Optic Cable Warning
5 Amb FbrOp Ambient Fiber Optic Warning
6 Inv OvrVolt Inverter Over Voltage Warning
7 InvACCurGain Inverter AC Current Gain Warning
8 AIn1 Cal Err -
9 AIn2 Cal Err -
10 AIn3 Cal Err -
11 PFC IdcLimit Idc Limit has been reached while compensating for input power
factor
12 PFC FlxLimit Flux Limit has been reached while compensating for input power
factor
13 ProcVar Loss Process variable loss has been detected
14 Unused
15 Unused
Motor Warning Word 1 [Motor Warning1]
Linear Number: 373
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the first warning word corresponding to motor side fault
detection. A ‘1’ represents an active warning as follows:
Bit Enum Text Description
0 Mtr OvrLoad Motor Overload warning
1 Mtr CapRange Motor Capacitor Out of Range Warning
2 Mtr LoadLoss Motor Load Loss Warning
3 Mtr OvrVolt Motor Over Voltage Warning
4 Unused
5 Byp OvrVolt Bypass Contactor Over Voltage Warning
6 Byp UndrVolt Bypass Contactor Under Voltage Warning
7 Byp Unbal Bypass Contactor Unbalance Warning
8 Byp Phs Seq Bypass Contactor Phase Sequence Warning
9 SyncXferFail Synchronous Transfer Fail Warning
10 Desync Delay De-synchronization delay Warning
11 Tach Loss Tach Loss Warning
12 Tach Dir Tach Direction is latched to the one before tach phase loss
13 TachPhA Loss Tach Phase A Loss Warning
14 No Tach No Tach Installed Warning
15 TachPhB Loss Tach Phase B Loss Warning
