Parameters Listed by Linear Number 2-221
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
111 RecHSink TempTrp 0 100 55 C N Service
112 RecHSink TempWrn 0 100 53 C N Service
113 CurReg Bandwidth 50.0 2000.0 200.0 r/s N Advanced
114 DCLnk Induct pu 0.00 10.00 - pu Y Service
115 T DC Link 0.015 0.150 0.040 sec N Advanced
116 DC Link Current 0 999 - A Y Basic
117 Bypass Voltage 0.000 2.000 - pu Y Advanced
118 Control AC#1 RMS 0.0 300.0 - V Y Advanced
119 Idc Test Command 0.000 1.500 0.000 pu N Advanced
120 Idc Ref Step 0.000 1.000 0.000 pu N Advanced
121 Control 56V 0.0 72.0 - V Y Advanced
122 Line Current pu 0.000 4.000 - pu Y Service
123 Anlg Out4 Scale 0.00 655.35 1.00 N Basic
124 Anlg RecTstPt3 0 779 326 N Service
125 Anlg RecTstPt4 0 779 700 N Service
126 Anlg InvTstPt3 0 779 291 N Service
127 Anlg InvTstPt4 0 779 306 N Service
128 Motor Filter Cap 0.00 2.00 - pu Y Service
129 R Stator 0.0000 0.5000 0.0000 pu N Advanced
130 L Total Leakage 0.00 0.75 0.25 pu N Advanced
131 Lm Rated 1.00 15.00 3.50 pu N Advanced
132 T Rotor 0.10 10.00 1.50 sec N Advanced
133 Line Filter Cap 0.00 2.00 - pu Y Service
134 Lm Measured 0.00 15.00 - pu Y Service
135 Line Voltage pu 0.000 2.000 - pu Y Service
136 Master Line Volt 0.000 2.000 - pu Y Service
137 Slave1 Line Volt 0.000 2.000 - pu Y Service
138 Slave2 Line Volt 0.000 2.000 - pu Y Service
139 Control 5V 0.0 8.0 - V Y Advanced
140 Input Impedance 0.0000 1.0000 0.0500 pu N Service
141 HardwareOptions1 - - 0000000010000000 N Service
142 Control 15V 0.0 24.0 - V Y Advanced
143 InvDvc CurRating 0 3500 800 A N Service
144 RecDvc CurRating 0 3500 800 A N Service
145 Series RecDvc 1 6 2 N Service
146 Series InvDvc 1 6 2 N Service
147 Active Trq Limit -4.000 4.000 - Y Advanced
148 DPI Loss Warning - - - Y Service
149 CT Ratio Line 10 10000 1000 N Service
150 HECS Ratio Motor 10 10000 4000 N Service
151 CT Brden Line 1.0 100.0 5.0 ohms N Service
152 HECS Brden Motor 1.0 100.0 50.0 ohms N Service
153 Rectifier Type - - 6 PWM N Service
154 Inv PWM Max Freq 100 1000 440 Hz N Service
155 Rec PWM Max Freq 100 1000 440 Hz N Service
156 Control HECS 0.0 36.0 - V Y Advanced
157 CT Ratio Gndflt 10 10000 2000 N Service
158 CT Burden Gndflt 10 10000 1000 ohms N Service
159 Bypass Frequency -100.0 100.0 - Hz Y Advanced
160 RecControl Flag2 - - - Y Service
161 Line OvrCur Trp 0.00 4.00 1.75 pu N Advanced
162 Line OvrCur Dly 0 100 10 msec N Advanced
163 Drv OvrLoad Trp 0.00 4.00 1.15 pu N Advanced
164 Drv OvrLoad Dly 0.0 600.0 60.0 sec N Advanced
165 Line OvrVolt Trp 0.00 2.00 1.20 pu N Advanced
166 Line OvrVolt Dly 0 1000 10 msec N Advanced
