Rockwell Automation PowerFlex 7000 Technical Data

2-222 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
167 Line UndVolt Lvl 0.40 1.50 0.85 pu N Advanced
168 Line UndVolt Dly 0 100 17 msec N Advanced
169 DCLnk OvrCur Trp 0.00 4.00 1.75 pu N Advanced
170 DCLnk OvrCur Dly 0 100 10 msec N Advanced
171 Gnd OvrCur Trp 0.05 10.00 0.50 A N Advanced
172 Gnd OvrCur Dly 0.0 10.0 0.1 sec N Advanced
173 Rec OvrVolt Trp 0.00 2.00 1.50 pu N Advanced
174 Rec OvrVolt Dly 0 100 10 msec N Advanced
175 DPI Loss Mask - - 0000000000000000 N Basic
176 Drive Model - - B Frame N Service
177 Mtr OvrCur Trp 0.00 4.00 1.75 pu N Advanced
178 Mtr OvrCur Dly 0 500 100 msec N Advanced
179 Mtr OvrLoad Trp 0.00 4.00 1.15 pu N Advanced
180 Mtr OvrLoad Dly 0.0 600.0 60.0 sec N Advanced
181 Mtr OvrVolt Trp 0.00 2.00 1.20 pu N Advanced
182 Mtr OvrVolt Dly 0.0 10.0 0.5 sec N Advanced
183 Anlg Out1 Scale 0.00 655.35 1.00 N Basic
184 Anlg Out2 Scale 0.00 655.35 1.00 N Basic
185 Mtr OvrSpeed Trp 0.0 120.0 66.0 Hz N Advanced
186 Mtr OvrSpeed Dly 0.0 2.0 0.5 sec N Advanced
187 Anlg Out3 Scale 0.00 655.35 1.00 N Basic
188 Anlg4-20mA Scale 0.00 655.35 2.00 N Basic
189 Mtr NeutVolt Trp 0.00 1.50 0.20 pu N Advanced
190 Mtr NeutVolt Dly 0.0 10.0 1.0 sec N Advanced
191 Mtr Stall Dly 0.0 10.0 2.0 sec N Advanced
192 InpFilCutOffFreq 0.0 100.0 - Y Service
193 Inv OvrVolt Trp 0.00 2.00 1.50 pu N Advanced
194 Inv OvrVolt Dly 0 100 10 msec N Advanced
196 Control XIO 0.0 36.0 - V Y Advanced
197 HECS Brden RNeut 1.0 100.0 50.0 ohms N Service
198 HECS Ratio RNeut 10 10000 4000 N Service
199 Load Loss Detect - - Disabled N Advanced
200 ExtFault1 Class - - Class2 Fault N Basic
201 ExtFault2 Class - - Class2 Fault N Basic
202 ExtFault3 Class - - Class2 Fault N Basic
203 ExtFault4 Class - - Class2 Fault N Basic
204 ExtFault5 Class - - Class2 Fault N Basic
205 ExtFault6 Class - - Class2 Fault N Basic
206 ExtFault7 Class - - Class2 Fault N Basic
207 ExtFault8 Class - - Class2 Fault N Basic
208 Mtr CurUnbal Trp 0.00 1.00 0.05 pu N Advanced
209 Autotune Select - - Off N Advanced
210 Autotune Idc Cmd 0.100 0.900 0.500 pu N Advanced
211 Autotune Idc Stp 0.000 0.500 0.250 pu N Advanced
212 Autotune Idc BW 10.0 100.0 50.0 r/s N Advanced
213 Autotune Spd Cmd 20.0 60.0 30.0 Hz N Advanced
214 Mtr CurUnbal Dly 0.0 5.0 1.0 sec N Advanced
215 Autotune Trq Stp 0.050 0.500 0.100 pu N Advanced
216 Autotune Isd Stp 0.010 0.200 0.100 pu N Advanced
217 Autotune L Input 0.00 1.00 0.00 pu N Advanced
218 Autotune T DCLnk 0.000 0.150 0.000 sec N Advanced
219 Autotune RStator 0.00 0.50 0.00 pu N Advanced
220 Autotune LLeakge 0.00 0.50 0.00 pu N Advanced
221 Autotune L Magn 0.00 15.00 0.00 pu N Advanced
222 Autotune T Rotor 0.00 10.00 0.00 sec N Advanced
223 Autotune Inertia 0.00 100.00 0.00 sec N Advanced
