Rockwell Automation PowerFlex 7000 Technical Data

Parameters Listed by Linear Number 2-223
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
224 Autotune Lmd 0.00 10.00 0.00 pu N Advanced
225 Sync Reg Gain 0.0 5.0 1.0 N Advanced
226 Sync Lead Angle -90 90 0 deg N Advanced
227 Sync Off Delay 0.000 0.500 0.100 sec N Advanced
228 Sync Error Max 0 30 0 deg N Advanced
229 Sync Time 0.0 10.0 10.0 sec N Advanced
230 Sync Xfer Time 0.1 57.0 1.0 min N Advanced
231 Mtr LoadLoss Dly 0.0 30.0 1.0 sec N Advanced
232 Ext Fault XIO - - - Y Advanced
233 Tach Type - - None N Basic
234 Tach PPR 120 4096 1024 PPR N Basic
235 Tach Loss Trip 0.0 10.0 2.0 Hz N Service
236 Tach Loss Delay 0.0 1.0 0.1 sec N Service
237 Control 5V Redn 0.0 8.0 - V Y Advanced
238 DrvStatus Flag2 - - - Y Service
239 Slave2 Line Freq -100.0 100.0 - Hz Y Service
241 Logic Mask - - 11111111 N Basic
242 Local Mask - - 11111111 N Basic
243 Start Mask - - 11111111 N Basic
244 Direction Mask - - 11111111 N Basic
245 Jog Mask - - 11111111 N Basic
246 Mtr LoadLoss Lvl 0.00 1.00 0.25 pu N Advanced
247 Reset Mask - - 11111111 N Basic
248 Ref Cmd Mask - - 11111111 N Basic
249 Sync Xfer Mask - - 11111111 N Basic
251 InvAnlg SelfTst2 - - - Y Service
252 Inv HSink Temp C -40.0 100.0 - C Y Monitor
253 Inv HSink Temp F -40.0 212.0 - F Y Monitor
254 Rec HSink Temp C -40.0 100.0 - C Y Monitor
255 Rec HSink Temp F -40.0 212.0 - F Y Monitor
257 Logic Command - - - Y Monitor
258 Logic Status - - - Y Monitor
259 Mtr LoadLoss Spd 0.0 100.0 30.0 Hz N Advanced
260 IdcRefLmt DCTest 0.000 4.000 - pu Y Service
261 IdcRefLmt Autotn 0.000 4.000 - pu Y Service
262 Drive Not Ready1 - - - Y Monitor
263 Motor Cur Unbal 0.00 1.00 - Y Service
264 RecControl Flag1 - - - Y Service
265 InvControl Flag1 - - - Y Service
266 Rec Dvc Diag Dly 0 6 2 N Service
268 Inv Dvc Diag Dly 0 6 2 N Service
269 Drv OvrLoad Min 0.00 4.00 1.05 pu N Advanced
270 Drv OvrLoad Wrn 0.00 1.00 0.50 N Advanced
271 LineVoltUnbalTrp 0.00 1.00 0.05 pu N Advanced
272 LineVoltUnbalDly 0.0 10.0 1.0 sec N Advanced
273 Control Feedback 0.0 6553.5 - Hz Y Basic
274 HardwareOptions2 - - 0000000000000000 N Service
275 Control Refernce 0.0 6553.5 - Hz Y Basic
276 Speed Command In -120.0 120.0 - Hz Y Basic
277 Speed Command -120.0 120.0 - Hz Y Basic
278 Speed Reference -120.0 120.0 - Hz Y Monitor
279 Drive Fault1 - - - Y Service
280 Drive Fault2 - - - Y Service
281 Drive Fault3 - - - Y Service
282 Drive Warning1 - - - Y Service
284 HECS Ratio DCLnk 10 10000 4000 N Service
