Rockwell Automation PowerFlex 7000 Technical Data

2-224 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
285 HECS Brden DCLnk 1.0 100.0 50.0 ohms N Service
287 Ctrl Pwr Fault - - - Y Service
288 Ctrl Pwr Warning - - - Y Service
289 Speed Feedback -120.0 120.0 - Hz Y Monitor
290 Speed Cmd Max 0.0 120.0 60.0 Hz N Basic
291 Torque Reference -4.000 4.000 - Y Advanced
292 MtrTorque CurCmd -4.000 4.000 - pu Y Advanced
293 Speed Cmd Min 0.0 120.0 6.0 Hz N Basic
294 InvTorque CurCmd -4.000 4.000 - pu Y Advanced
295 Inv Pulse Number 0 65535 - Y Service
296 Lmq 0.10 10.00 1.00 pu N Advanced
297 Sync Reg Error -180.0 180.0 - deg Y Advanced
298 Sync Reg Output -10.00 10.00 - Hz Y Advanced
299 PFC Access Code 0 65535 0 N Service
300 PowerFactor Comp - - Disable N Service
301 PFC LeadingLimit 0.00 1.00 0.00 N Service
302 PFC LaggingLimit 0.00 1.00 0.00 N Service
304 PFC Flux Command -1.500 1.500 - pu Y Service
305 Flux Reference 0.000 2.000 - pu Y Advanced
306 Flux Feedback 0.000 2.000 - pu Y Advanced
307 Flux Error -2.000 2.000 - pu Y Advanced
308 FluxCur Feedfwd -2.000 2.000 - pu Y Advanced
309 FluxCurRegulator -2.000 2.000 - pu Y Advanced
310 Mtr Flux CurCmd -2.000 2.000 - pu Y Advanced
311 PFC Mod Index 0.00 1.50 - Y Service
312 Inv Flux CurCmd -2.000 2.000 - pu Y Advanced
313 PID Command - - 0000000000000000 N Service
314 Field CurCmd 0.000 2.000 - pu Y Advanced
315 InvHSink TempTrp 0 100 64 C N Service
316 InvHSink TempWrn 0 100 61 C N Service
317 Conv AirFlow Nom 0.0 10.0 3.6 V N Service
318 PID Max Limit -2.0000 2.0000 1.0000 pu N Advanced
319 Conv AirFlow Trp 0.0 10.0 2.5 V N Service
320 Conv AirFlow Wrn 0.0 10.0 3.0 V N Service
321 Idc Reference 0.000 4.000 - pu Y Advanced
322 Idc Feedback -2.000 4.000 - pu Y Advanced
323 Idc Error -1.000 1.000 - pu Y Advanced
324 Line Voltage 0 8000 - V Y Basic
325 Autotune Lmq 0 1000 100 pu N Advanced
326 Vdc Reference -1.000 1.000 - Y Advanced
327 Alpha Rectifier 0.0 180.0 - deg Y Advanced
328 Alpha Inverter -360.0 360.0 - deg Y Advanced
334 Master Line Freq -100.0 100.0 - Hz Y Service
335 Slave1 Line Freq -100.0 100.0 - Hz Y Service
336 PID Min Limit -2.0000 2.0000 -1.0000 pu N Advanced
337 Rotor Frequency 0.00 120.00 - Hz Y Monitor
338 MtrFlux Current -4.000 4.000 - pu Y Service
339 MtrTrq Current -4.000 4.000 - pu Y Service
340 Stator Current 0.000 4.000 - pu Y Monitor
341 FlxFbk CurModel 0.000 2.000 - pu Y Service
342 FlxFbk VoltModel 0.000 2.000 - pu Y Service
343 Slip Frequency -2.00 2.00 - Hz Y Monitor
344 Stator Voltage 0.000 2.000 - pu Y Monitor
345 Mtr AirGap Trq -4.000 4.000 - pu Y Monitor
346 Mtr AirGap Power -4.000 4.000 - pu Y Monitor
347 Mtr Neutral Volt -2.000 2.000 - pu Y Basic
