Rockwell Automation PowerFlex 7000 Technical Data

2-92 Parameter Descriptions
7000-TD002A-EN-P – September 2007
Drive Warning Mask 4 [Drv Wrn4 Mask]
Linear Number: 468
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the fourth warning word corresponding to drive protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 ConvFn1Ctctr Converter Fan 1 Contactor Feedback Loss Warning
1 ConvFn2Ctctr Converter Fan 2 Contactor Feedback Loss Warning
2 Iso Fn1Ctctr Isolation Transformer Fan 1 Contactor Feedback Loss Warning
3 Iso Fn2Ctctr Isolation Transformer Fan 2 Contactor Feedback Loss Warning
4 Conv AirFlow Converter Air Flow Pressure Value Warning
5 Iso AirFlow Isolation Transformer Air Flow Pressure Value Warning
6 Conv FansOn Converter Cooling Fans On Warning
7 IsoTxFans On Isolation Transformer Cooling Fans On Warning
8 ConvFan1Loss Converter Fan 1 Loss Warning
9 ConvFan2Loss Converter Fan 2 Loss Warning
10 IsoFan1 Loss Isolation Transformer Fan 1 Loss Warning
11 IsoFan2 Loss Isolation Transformer Fan 2 Loss Warning
12 Drv Maintain Drive Maintenance Warning
13 Inv Gate Pwr Inverter Gating Power Loss Warning
14 Unused
15 Unused
Drive Warning Mask 5 [Drv Wrn5 Mask]
Linear Number: 707
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the fifth warning word corresponding to drive protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 InvHSnkOvTmp Inverter Heat Sink Over Temperature Warning
1 Amb OvTmp Ambient Over Temperature Warning
2 InvHSnk Sens Inverter Heat Sink Sensor Warning
3 Amb Sens Ambient Sensor Warning
4 InvHSnkFbrOp Inverter Heat Sink Fiber Optic Cable Warning
5 Amb FbrOp Ambient Fiber Optic Warning
6 Inv OvrVolt Inverter Over Voltage Warning
7 InvACCurGain Inverter AC Current Gain Warning
8 Unused
9 Unused
10 Unused
11 PFC IdcLimit Idc Limit has been reached while compensating for input power
factor
12 PFC FlxLimit Flux Limit has been reached while compensating for input power
factor
13 ProcVarLossW Process variable loss has been detected
14 Unused
15 Unused
