Parameter Descriptions 2-91
7000-TD002A-EN-P – September 2007
Drive Warning Mask 2 [Drv Wrn2 Mask]
Linear Number: 647
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the second warning word corresponding to drive protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 RecHSnk Sens Rectifier Heatsink sensor Loss Warning
1 RecChB Sens Rectifier Channel B Sensor Loss Warning
2 RecHSnkFbrOp Rectifier Heatsink Fiber Optic Loss Warning
3 RecChB FbrOp Rectifier Channel B Fiber Optic Loss Warning
4 RecDCCurGain Rectifier DC Current Gain Warning
5 Rec Gate Pwr Rect Gate Power Supply Warning
6 RecACCurGain Rectifier AC Current Gain Warning
7 Stack Depth Black Box Stack Depth
8 BlkBox NVRAM Black Box NVRAM Cleared Warning
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
Drive Warning Mask 3 [Drv Wrn3 Mask]
Linear Number: 423
Default Value: 1111111111111111
Access Level: Basic
Read/Write: Read/Write
This parameter specifies the mask for the third warning word corresponding to drive protection. A ‘1’
represents an enabled warning; a ‘0’ represents a disabled warning. The bit assignment is:
Bit Enum Text Description
0 InpCtctrOpen Input Contactor Open warning
1 InpCtctrClsd Input Contactor Closed warning
2 OutCtctrOpen Output Contactor Open warning
3 OutCtctrClsd Output Contactor Closed warning
4 BypCtctrOpen Bypass Contactor Open warning
5 BypCtctrClsd Bypass Contactor Closed warning
6 Inp IsoOpen Drive Input Isolation Switch Open warning
7 Out IsoOpen Drive Output Isolation Switch Open warning
8 Byp IsoOpen Bypass Isolation Switch Open warning
9 Inp IsoClsd Input Isolation Switch Closed warning
10 Out IsoClsd Output Isolation Switch Closed warning
11 Byp IsoClsd Bypass Isolation Switch Closed warning
12 No Out Ctctr No Output contactor installed Warning
13 InpClose Dly Input Contactor Close Delay
14 Unused
15 Unused
