Parameter Descriptions 2-101
7000-TD002A-EN-P – September 2007
Drive Fault Word 6 [Drive Fault6]
Linear Number: 9
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the sixth fault word corresponding to drive protection.
These faults can be either Class 1 or Class 2. A ‘1’ represents an active fault as follows:
Bit Enum Text Description
0 DAN Comm Drive Area Network Communication Fault – Parallel Drive Application
1 Mstr Xfr Err Master Transfer Error
2 PDCapcityLow Parallel Drive capacity is low
3 Main VSB Main Voltage Sensing Board has not been plugged in to ACB
4 Sync VSB Bypass Voltage Sensing Board has not been plugged in to ACB
5 DC Neut VSB DC and Neutral Sensing Board has not been plugged in to ACB
6 InpLock5min Input contactor is locked out for 5 minute (line over current in 18-pulse
drives)
7 InpLockIndef Input contactor is locked out indefinitely (line over current and PLL
error in 18-pulse drives)
8 ProcVar Loss Process Variable from the customer process sensor is lost
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
Motor Fault Word 1 [Motor Fault1]
Linear Number: 369
Access Level: Service
Read/Write: Read Only
This parameter displays the bit assignment on the first fault word corresponding to motor side fault
detection. These faults can be either Class 1 or Class 2. A ‘1’ represents an active fault as follows:
Bit Enum Text Description
0 Mtr OvrCur Motor Over current fault
1 Mtr OvrVolt Motor Overvoltage fault
2 MtrNeuOvrVol Drive Output contactor fault
3 Mtr FlxUnbal Motor Flux Unbalance Fault
4 Mtr CurUnbal Motor Current Unbalance Fault
5 Mtr OvrLoad Motor Over Load Fault
6 Mtr OvrSpeed Motor Over Speed
7 Mtr Stall Motor Stall fault
8 Mtr LoadLoss Motor Load Loss Fault
9 SynFieldLoss Synchronous Field Loss Fault
10 MtrSlipRange Motor Slip Out of Range Fault
11 Unused
12 Unused
13 Unused
14 Unused
15 Unused
