Parameter Descriptions 2-183

7000-TD002A-EN-P – September 2007

Drive2 Status [Drive2 Status]

Linear Number: 726

Access Level: Advanced

Read/Write: Read Only

These eight variables display the status of all the drives in a parallel drive system. They are valid in the

master drive only, and will have a value of zero in all slave drives. The definition is the same as PD Status.

Bit Enum Text Description

0 Ready Drive is ready

1 Running Drive is running

2 Faulted Drive has a fault condition

3 Class1 Fault Drive has a class 1 fault

4 Class2 Fault Drive has a class 2 fault

5 Hub Comm OK Communications between the drive and the hub PLC is functional

6 Input Clsed Drive input contactor is closed

7 Output Clsed Drive output contactor is closed

8 Unused

9 Unused

10 Unused

11 Unused

12 Unused

13 Unused

14 Unused

15 Status Valid Status word is valid

Drive3 Status [Drive3 Status]

Linear Number: 727
