Parameter Descriptions 2-185
7000-TD002A-EN-P – September 2007
Drive6 Status [Drive6 Status]
Linear Number: 730
Access Level: Advanced
Read/Write: Read Only
These eight variables display the status of all the drives in a parallel drive system. They are valid in the
master drive only, and will have a value of zero in all slave drives. The definition is the same as PD Status.
Bit Enum Text Description
0 Ready Drive is ready
1 Running Drive is running
2 Faulted Drive has a fault condition
3 Class1 Fault Drive has a class 1 fault
4 Class2 Fault Drive has a class 2 fault
5 Hub Comm OK Communications between the drive and the hub PLC is functional
6 Input Clsed Drive input contactor is closed
7 Output Clsed Drive output contactor is closed
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Status Valid Status word is valid
Drive7 Status [Drive7 Status]
Linear Number: 731
Access Level: Advanced
Read/Write: Read Only
These eight variables display the status of all the drives in a parallel drive system. They are valid in the
master drive only, and will have a value of zero in all slave drives. The definition is the same as PD Status.
Bit Enum Text Description
0 Ready Drive is ready
1 Running Drive is running
2 Faulted Drive has a fault condition
3 Class1 Fault Drive has a class 1 fault
4 Class2 Fault Drive has a class 2 fault
5 Hub Comm OK Communications between the drive and the hub PLC is functional
6 Input Clsed Drive input contactor is closed
7 Output Clsed Drive output contactor is closed
8 Unused
9 Unused
10 Unused
11 Unused
12 Unused
13 Unused
14 Unused
15 Status Valid Status word is valid
