2-202 Parameters Listed by Group
7000-TD002A-EN-P – September 2007
Diagnostics Parameters
Name Min. Max. Default Units
Read-
Only
Access
257 Logic Command - - - Hex Y Monitor
258 Logic Status - - - Hex Y Monitor
262 Drive Not Ready1 - - - Hex Y Monitor
699 Drive Not Ready2 - - - Hex Y Monitor
569 DrvStatus Flag1 - - - Hex Y Service
238 DrvStatus Flag2 - - - Hex Y Service
505 Contactor Cmd - - - Hex Y Service
506 Contactor Status - - - Hex Y Service
264 RecControl Flag1 - - - Hex Y Service
160 RecControl Flag2 - - - Hex Y Service
368 RecControl Flag3 - - - Hex Y Service
265 InvControl Flag1 - - - Hex Y Service
642 InvControl Flag2 - - - Hex Y Service
446 InvControl Flag3 - - - Hex Y Service
96 InvAnlg SelfTst1 - - - Hex Y Service
251 InvAnlg SelfTst2 - - - Hex Y Service
473 RecAnlg SelfTst1 - - - Hex Y Service
474 RecAnlg SelfTst2 - - - Hex Y Service
494 RecAnlg SelfTst3 - - - Hex Y Service
764 Cur Sens FltCode - - - Hex Y Service
551 Drive Overload 0.00 1.00 - Y Service
550 Motor Overload 0.00 1.00 - Y Service
682 RNeutral OvrLoad 0.00 1.00 - Y Service
428 Bypass VoltUnbal 0.00 1.00 - Y Service
610 Master VoltUnbal 0.00 1.00 - Y Service
611 Slave1 VoltUnbal 0.00 1.00 - Y Service
612 Slave2 VoltUnbal 0.00 1.00 - Y Service
613 Master Cur Unbal 0.00 1.00 - Y Service
614 Slave1 Cur Unbal 0.00 1.00 - Y Service
615 Slave2 Cur Unbal 0.00 1.00 - Y Service
263 Motor Cur Unbal 0.00 1.00 - Y Service
619 Motor Flux Unbal 0.00 1.00 - Y Service
490 Fault Output 0 1 - Y Service
700 Warning Output 0 1 - Y Service
689 Scope Trigger 0 1 - Y Service
597 Parameter Error 0 65535 - Y Basic
