Rockwell Automation PowerFlex 7000 Technical Data

2-230 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
723 PD Status - - - Y Service
724 Drive0 Status - - - Y Advanced
725 Drive1 Status - - - Y Advanced
726 Drive2 Status - - - Y Advanced
727 Drive3 Status - - - Y Advanced
728 Drive4 Status - - - Y Advanced
729 Drive5 Status - - - Y Advanced
730 Drive6 Status - - - Y Advanced
731 Drive7 Status - - - Y Advanced
732 Master Flux Ref 0 65535 - Y Service
733 Master Torq Ref 0 65535 - Y Service
734 Master Isd Cmd 0 65535 - Y Service
735 Master Command - - - Y Service
736 Sp Slave ID 0 8 - Y Service
737 Master Capacity 0 65535 - Y Service
738 Sp Capacity 0 65535 - Y Service
739 Sp Command - - - Y Service
740 PD Flux Ref 0 65535 - Y Service
741 PD Torq Ref 0 65535 - Y Service
742 PD Isd Cmd 0 65535 - Y Service
743 PD Command - - - Y Service
745 Drives in System 1 4 1 N Advanced
746 PD Capacity 0 32767 - Y Service
747 Pwr Lmt Motoring 0.00 4.00 1.50 N Advanced
748 Pwr Lmt Braking 0.00 4.00 1.50 N Advanced
749 Speed Cmd Loss - - Fault N Basic
750 ESP Cable Resis 0.000 65.535 0.000 ohms N Service
751 Drv Application - - ID Fan N Basic
753 Input Power -15000 15000 - kW Y Service
756 Idc 3 Pulse 0.000 10.000 - pu Y Service
757 Idc 5 Pulse 0.000 10.000 - pu Y Service
758 PD Warning - - - Y Service
759 PD Wrn Mask - - 1111111111111111 N Service
760 ESP Surface Volt 0 8000 - V Y Basic
761 Inv Output Volt 0.000 2.000 - pu Y Service
763 DeSync Start Dly 1 10 1 sec N Service
764 Cur Sens FltCode - - - Y Service
765 Reduced Capacity - - Enable N Advanced
767 BusTransient Lvl 0.000 32.767 - pu Y Service
771 Mtr Thermal Cyc 0.0 6000.0 600.0 Sec N Advanced
772 Drv Thermal Cyc 0.0 6000.0 600.0 sec N Advanced
773 IdcRefLmt Motor 0.000 4.000 - pu Y Service
774 RNeut OvrLoadTrp 0.00 655.35 5.00 N Service
775 RNeut OvrLoadDly 0.00 655.35 2.50 sec N Service
776 RNeut OvrCurTrp 0.00 655.35 10.00 N Service
777 RNeut OvrCurDly 0.000 65.535 0.010 sec N Service
778 TransientVoltMax 0.000 2.000 - pu Y Service
779 ComModeCur Peak 0.00 655.35 - A Y Service
