Rockwell Automation PowerFlex 7000 Technical Data

2-232 Alphabetical Index
7000-TD002A-EN-P – September 2007
No. ParameterName Page
447 Convrter AirFlow........................ 6
380 Coolant Temp C......................... 173
381 Coolant Temp F......................... 173
483 Coolant Temp Trp...................... 174
478 Coolant Temp Wrn..................... 174
287 Ctrl Pwr Fault............................. 105
104 Ctrl Pwr FltMask ........................ 93
288 Ctrl Pwr Warning........................ 106
105 Ctrl Pwr WrnMask...................... 94
764 Cur Sens FltCode...................... 20
113 CurReg Bandwidth..................... 69
D
116 DC Link Current......................... 166
114 DCLnk Induct pu........................ 32
27 DCLnk Inductance..................... 36
170 DCLnk OvrCur Dly..................... 109
169 DCLnk OvrCur Trp..................... 109
442 DCLnkOvrTmpClass.................. 80
93 DPI Loss Fault ........................... 106
175 DPI Loss Mask........................... 94
148 DPI Loss Warning...................... 107
763 DeSync Start Dly ....................... 127
69 Decel Time 1.............................. 64
70 Decel Time 2.............................. 64
71 Decel Time 3.............................. 64
72 Decel Time 4.............................. 64
244 Direction Mask........................... 129
388 Direction Owner......................... 134
279 Drive Fault1 ............................... 98
280 Drive Fault2 ............................... 99
281 Drive Fault3 ............................... 99
370 Drive Fault4 ............................... 100
371 Drive Fault5 ............................... 100
9 Drive Fault6 ............................... 101
716 Drive ID...................................... 178
176 Drive Model................................ 33
262 Drive Not Ready1 ...................... 11
699 Drive Not Ready2 ...................... 12
551 Drive Overload........................... 21
648 Drive VSB Gain.......................... 33
649 Drive VSB Tap........................... 33
282 Drive Warning1.......................... 102
646 Drive Warning2.......................... 102
374 Drive Warning3.......................... 103
467 Drive Warning4.......................... 103
706 Drive Warning5.......................... 104
724 Drive0 Status ............................. 182
725 Drive1 Status ............................. 182
726 Drive2 Status ............................. 183
727 Drive3 Status ............................. 183
728 Drive4 Status ............................. 184
729 Drive5 Status ............................. 184
730 Drive6 Status ............................. 185
731 Drive7 Status ............................. 185
745 Drives in System........................ 179
751 Drv Application........................... 190
No. ParameterName Page
394 Drv Fault1 Mask ........................ 87
395 Drv Fault2 Mask ........................ 87
396 Drv Fault3 Mask ........................ 88
562 Drv Fault4 Mask ........................ 88
563 Drv Fault5 Mask ........................ 89
8 Drv Fault6 Mask ........................ 89
164 Drv OvrLoad Dly........................ 113
269 Drv OvrLoad Min ....................... 113
163 Drv OvrLoad Trp........................ 113
270 Drv OvrLoad Wrn ...................... 112
772 Drv Thermal Cyc ....................... 113
397 Drv Wrn1 Mask.......................... 90
647 Drv Wrn2 Mask.......................... 91
423 Drv Wrn3 Mask.......................... 91
468 Drv Wrn4 Mask.......................... 92
707 Drv Wrn5 Mask.......................... 92
569 DrvStatus Flag1......................... 12
238 DrvStatus Flag2......................... 13
420 DvcDiag Flt Mask ...................... 95
E
750 ESP Cable Resis....................... 189
760 ESP Surface Volt....................... 189
644 Encoder Offset .......................... 128
564 Ext Fault Mask........................... 86
650 Ext Fault PLC ............................ 108
651 Ext Fault Selct ........................... 82
232 Ext Fault XIO ............................. 151
200 ExtFault1 Class ......................... 82
411 ExtFault10 Class ....................... 84
412 ExtFault11 Class ....................... 85
413 ExtFault12 Class ....................... 85
414 ExtFault13 Class ....................... 85
415 ExtFault14 Class ....................... 85
416 ExtFault15 Class ....................... 86
417 ExtFault16 Class ....................... 86
201 ExtFault2 Class ......................... 82
202 ExtFault3 Class ......................... 83
203 ExtFault4 Class ......................... 83
204 ExtFault5 Class ......................... 83
205 ExtFault6 Class ......................... 83
206 ExtFault7 Class ......................... 84
207 ExtFault8 Class ......................... 84
410 ExtFault9 Class ......................... 84
702 Extended Trend......................... 29
372 External Fault ............................ 97
429 External Warning....................... 98
F
477 Fan Config................................. 174
449 Fan Duty Cycle.......................... 175
491 Fan1 Run Time.......................... 30
493 Fan2 Run Time.......................... 30
490 Fault Output............................... 23
502 Feedforward Fil ......................... 70
106 Field Bandwidth......................... 79
314 Field CurCmd ............................ 77
