2-234 Alphabetical Index
7000-TD002A-EN-P – September 2007
No. ParameterName Page
588 LineNeutVoltDly......................... 114
587 LineNeutVoltTrp......................... 113
589 LineNeutral Volt ......................... 6
272 LineVoltUnbalDly ....................... 111
271 LineVoltUnbalTrp....................... 111
703 Liq Cool Mask............................ 95
358 Liquid Cool Flt............................ 108
359 Liquid Cool Wrn ......................... 109
52 Liquid Inputs .............................. 152
14 Liquid Outputs............................ 153
134 Lm Measured............................. 52
695 Lm Noload FlxMax..................... 53
694 Lm Noload FlxMin...................... 53
701 Lm Predicted.............................. 52
131 Lm Rated ................................... 52
693 Lm Regen .................................. 53
418 Lmd............................................ 55
296 Lmq............................................ 55
199 Load Loss Detect....................... 27
242 Local Mask................................. 130
386 Local Owner............................... 135
257 Logic Command......................... 10
241 Logic Mask................................. 130
710 Logic Mask Act .......................... 176
94 Logic Owner............................... 137
258 Logic Status............................... 11
687 Logix Inputs ............................... 153
688 Logix Outputs............................. 154
714 Logix Register A ........................ 163
715 Logix Register B ........................ 164
M
737 Master Capacity......................... 186
735 Master Command ...................... 187
613 Master Cur Unbal....................... 22
732 Master Flux Ref ......................... 186
734 Master Isd Cmd ......................... 186
382 Master Line Cur ......................... 7
334 Master Line Freq........................ 8
136 Master Line Volt......................... 7
718 Master Mask .............................. 178
663 Master Phasing.......................... 194
733 Master Torq Ref......................... 186
610 Master VoltUnbal ....................... 21
679 Min Freewhl Time ...................... 116
28 Motor Cap Freq.......................... 36
21 Motor Cap Volts......................... 36
20 Motor Cap kVAR........................ 36
263 Motor Cur Unbal ........................ 23
361 Motor Current............................. 164
555 Motor Current pu........................ 4
369 Motor Fault1............................... 101
128 Motor Filter Cap......................... 32
78 Motor Flux Time......................... 78
619 Motor Flux Unbal ....................... 23
550 Motor Overload.......................... 21
364 Motor Power .............................. 165
No. ParameterName Page
443 Motor Prot Class........................ 81
487 Motor Speed Hz ........................ 164
363 Motor Speed RPM..................... 164
30 Motor Type ................................ 43
362 Motor Voltage............................ 164
554 Motor Voltage pu....................... 4
373 Motor Warning1......................... 104
346 Mtr AirGap Power...................... 50
345 Mtr AirGap Trq........................... 50
214 Mtr CurUnbal Dly....................... 123
208 Mtr CurUnbal Trp....................... 123
561 Mtr Fault1 Mask......................... 90
310 Mtr Flux CurCmd....................... 75
586 Mtr FluxUnbalDly....................... 123
585 Mtr FluxUnbalTrp....................... 123
231 Mtr LoadLoss Dly ...................... 124
246 Mtr LoadLoss Lvl....................... 123
259 Mtr LoadLoss Spd ..................... 124
190 Mtr NeutVolt Dly ........................ 121
189 Mtr NeutVolt Trp........................ 120
347 Mtr Neutral Volt.......................... 6
178 Mtr OvrCur Dly........................... 120
177 Mtr OvrCur Trp .......................... 120
180 Mtr OvrLoad Dly ........................ 121
350 Mtr OvrLoad Min........................ 122
179 Mtr OvrLoad Trp........................ 121
351 Mtr OvrLoad Wrn....................... 122
186 Mtr OvrSpeed Dly...................... 121
185 Mtr OvrSpeed Trp...................... 121
182 Mtr OvrVolt Dly.......................... 120
181 Mtr OvrVolt Trp.......................... 120
692 Mtr Power Factor....................... 51
191 Mtr Stall Dly............................... 122
771 Mtr Thermal Cyc........................ 122
565 Mtr Wrn1 Mask.......................... 93
338 MtrFlux Current ......................... 51
292 MtrTorque CurCmd ................... 60
339 MtrTrq Current........................... 51
N
680 Neutral Resistor......................... 39
575 Number PwrSup........................ 41
O
4 Operating Mode......................... 24
427 OptXIO Output........................... 152
5 Output Ctctr Cfg ........................ 27
P
746 PD Capacity............................... 188
743 PD Command............................ 189
720 PD Fault Word........................... 180
722 PD Flags.................................... 180
740 PD Flux Ref............................... 188
742 PD Isd Cmd............................... 188
723 PD Status .................................. 181
741 PD Torq Ref............................... 188
