Rockwell Automation PowerFlex 7000

242 Linear Number Index
7000-TD002A-EN-P – September 2007
No. ParameterName Page
349 Tach Feedback.......................... 127
350 Mtr OvrLoad Min........................ 122
351 Mtr OvrLoad Wrn....................... 122
352 PID Dead Band.......................... 192
353 PID Gain .................................... 191
354 PID Intgral Time......................... 191
355 PID Deriv Time .......................... 191
356 PID Output................................. 190
357 Process Variable........................ 190
358 Liquid Cool Flt............................ 108
359 Liquid Cool Wrn ......................... 109
360 Process Setpoint........................ 191
361 Motor Current............................. 164
362 Motor Voltage ............................ 164
363 Motor Speed RPM..................... 164
364 Motor Power .............................. 165
365 PID Preload ............................... 193
366 Process Var Eng........................ 191
367 GndFault Current....................... 166
368 RecControl Flag3....................... 15
369 Motor Fault1............................... 101
370 Drive Fault4 ............................... 100
371 Drive Fault5 ............................... 100
372 External Fault............................. 97
373 Motor Warning1 ......................... 104
374 Drive Warning3.......................... 103
375 AutotuneComplete..................... 49
376 PLC Error Flags......................... 138
377 Autotune Warning...................... 44
378 Inv PWM Pattern........................ 169
379 Vdc Ref 5p to 3p........................ 170
380 Coolant Temp C......................... 173
381 Coolant Temp F......................... 173
382 Master Line Cur ......................... 7
383 Slave1 Line Cur ......................... 7
384 Slave2 Line Cur ......................... 8
385 Stop Owner................................ 136
386 Local Owner............................... 135
387 Start Owner................................ 136
388 Direction Owner......................... 134
389 Jog Owner ................................. 134
390 PID Filter.................................... 193
391 Reset Owner.............................. 135
392 Ref Cmd Owner......................... 135
393 Sync Xfer Owner........................ 136
394 Drv Fault1 Mask......................... 87
395 Drv Fault2 Mask......................... 87
396 Drv Fault3 Mask......................... 88
397 Drv Wrn1 Mask.......................... 90
398 Process Gain ............................. 192
410 ExtFault9 Class.......................... 84
411 ExtFault10 Class........................ 84
412 ExtFault11 Class........................ 85
413 ExtFault12 Class........................ 85
414 ExtFault13 Class........................ 85
415 ExtFault14 Class........................ 85
416 ExtFault15 Class........................ 86
No. ParameterName Page
417 ExtFault16 Class ....................... 86
418 Lmd............................................ 55
420 DvcDiag Flt Mask ...................... 95
421 RunTime Input........................... 150
422 StndXIO Output......................... 150
423 Drv Wrn3 Mask.......................... 91
427 OptXIO Output........................... 152
428 Bypass VoltUnbal...................... 21
429 External Warning....................... 98
431 StndXIO FltInput........................ 151
432 Pump Duty Cycle....................... 174
433 Stnd XIO Fault........................... 96
434 Stnd XIO Warning ..................... 97
435 Stnd XIOFlt Mask ...................... 82
439 StndXIO Config1 ....................... 156
440 InputProt1 Class........................ 80
441 TxReacOvrTmpClss.................. 80
442 DCLnkOvrTmpClass ................. 80
443 Motor Prot Class........................ 81
444 InputProt2 Class........................ 81
445 Aux Prot Class........................... 81
446 InvControl Flag3........................ 17
447 Convrter AirFlow........................ 6
448 Stator Frequency....................... 50
449 Fan Duty Cycle.......................... 175
458 StndXIO Config2 ....................... 157
459 StndXIO Config3 ....................... 158
460 StndXIO Config4 ....................... 159
461 StndXIO Config5 ....................... 160
462 StndXIO Config6 ....................... 161
463 StndXIO Config7 ....................... 162
464 StndXIO Config8 ....................... 163
465 Vdc Ref 7p to 5p........................ 170
467 Drive Warning4.......................... 103
468 Drv Wrn4 Mask.......................... 92
472 Speed Error............................... 60
473 RecAnlg SelfTst1....................... 18
474 RecAnlg SelfTst2....................... 19
475 S Curve Percent ........................ 65
477 Fan Config................................. 174
478 Coolant Temp Wrn .................... 174
479 S Curve Decel 1 ........................ 66
480 S Curve Decel 2 ........................ 66
481 S Curve Accel 1......................... 65
482 S Curve Accel 2......................... 66
483 Coolant Temp Trp ..................... 174
485 StatFrqVoltModel....................... 51
486 StatFrqCurModel....................... 51
487 Motor Speed Hz ........................ 164
490 Fault Output............................... 23
491 Fan1 Run Time.......................... 30
493 Fan2 Run Time.......................... 30
494 RecAnlg SelfTst3....................... 19
500 Line Current............................... 165
502 Feedforward Fil ......................... 70
505 Contactor Cmd .......................... 13
506 Contactor Status........................ 14
