3-6 Troubleshooting
7000-TD002A-EN-P – September 2007
FAULT
MESSAGE
FAULT
CODE
DESCRIPTION RECOMMENDED ACTIONS
CoolantLevel Low
(C-Frame Only)
69 The measured coolant level within the
reservoir has dropped below the second
(lowest) level sensor and the drive has
faulted. This sensor is set for the minimum
level required to ensure there will be no air
drawn into the system through the reservoir.
– Verify that the drive cooling system does
not have any coolant leaks – repair if
found
– Add the proper amount of de-ionized
water to get the level above the warning
sensor (de-ionized water will evaporate,
not the glycol)
CoolantTemp High
(C-Frame Only)
67 The measured coolant temperature has
exceeded 54°C (129°F). The drive detected
that the coolant temperature has exceeded
the trip setting in P#483. Ensure that the
heat exchanger fans are working properly
and the room ambient is adequate for the
drive operation.
– Verify the heat exchanger fans are
operating
– Verify that the thermostatic valve is fully
opened
– Check that all valves are in the normal
operating position
– Verify that the drive is operating within
specified load and ambient conditions
CoolantTemp Low
(C-Frame Only)
66 The measured coolant temperature has
dropped below 4°C (40°F). It will not clear
until the coolant temperature reaches 10°C
(50°F). This fault will only occur if the drive
is not running, to stop you from starting with
a low coolant temperature. If you are
already running when the coolant level
drops, you will only get a warning.
– Verify that the thermostatic bypass valve
(V10) was not left open
– Verify that the ambient temperature
within the drive control room is not below
specification
– Warm up the control room ambient to get
the drive to an operational level
