Maintenance
A7-2 ENVI-MAG Manual
Optimum charging takes place at room temperature. Provision is made to
compensate for variation in temperature in the 0° to 40° Celsius temperature
range. The battery and console should also be at the same temperature.
To charge the batteries proceed as follows.
One battery
1. Connect the charger to the power outlet. Adjustment for different line
voltages are made automatically.
2. Connect the charger to the charger input connector.
3. Flip the switch on the charger to On.
4. Observe the charging light at the left hand side of the ENVI-MAG console. It
will be On while charging at a high rate and turn Off when the battery is
nearly charged.
Figure A - 43 Charger port and charging light.
Charger Input Connector
Charging Indicator Light
