Operating displays
ENVI-MAG Manual A3-37
Instrument
Auxiliary display
The Auxiliary display is accessible by pressing the “AUX/LCD” key. It provides
additional functions which are not directly accessible from the keyboard. You
will need to press the appropriate key to get to the function.
(+- ESC) LCD Intensity
(1) Data Output
(2) Factory Test # 0
(3) Lock OFF
(4) Reprogram System
Select function
Figure A-31 The auxiliary functions display.
Key pressed
Action under
auxiliary functions
=-0
These keys allow you to adjust the intensity of
the LCD screen for better viewing under a variety
of lighting conditions.
1
This option allows you to access the Data Output
menu to transfer information to your computer
or printer.
2
This function is reserved for production and
service tests. It has no functions for you to use.
3
The lock option allows you to lock the ENVI-MAG
setup parameters so that they are not acciden-
tally changed. To make any changes, you will have
to toggle this option first.
4
This option allows you to update the EPROM in
your ENVI-MAG with more functionality. The
software is supplied by SCINTREX.
3
auxiliary functions
To Next Page
