Fuse replacement
ENVI-MAG Manual A7-5
Maintenance
Fuse replacement
There is one fuse located inside the battery cover and another one is under the
metal cover of the External Heavy Duty Battery Pack.
Two fuses holders are provided under the battery cover of the ENVI-MAG, as
shown in Figure A - 44 on page A7-3. One is for a 1.5 A quick, standard North
American fuse (Scintrex P/N 512 018). The other fuse holder is for a 5 x 20mm
European fuse.
Caution: ONLY one fuse may be in place at any given time.
The fuse in the External Battery Pack (Scintrex P/N 512 049) is a standard 5 A
automotive fuse.
