ENVIMAP Reference
C3-12 ENVI-MAG Manual
Prepare the data
This group of menu options allows you to:
▲ transfer the data from the ENVI-MAG to your PC,
▲ configure the communications parameters between the PC
and the ENVI-MAG
▲ merge multiple files together into one.
This section allows you to adjust the communications speed between the
ENVI-MAG and your PC. The default setting of 9600 should suffice. You must also
ensure that the settings on the ENVI-MAG match those on your PC for the two
devices to properly communicate.
If you require frequent high-volume, high-speed data transfers from the
ENVI-MAG, contact SCINTREX for the optional DOWNLOAD program.
.
Figure C-12 Communication configuration with the ENVI-MAG
Filename
The name of the file to receive the ENVIMAG data. This file will
automatically be assigned an
.XYZ extension.
Dump instrument data
ENVIMAP Version 3.02.00
Dump the ENVI-MAG memory to an XYZ data file on the computer.
Review ALL the following steps before proceeding:
1. Enter the name of a file in which to place the data.
2. Connect the magnetometer to the COM1 or COM2 port of the computer
and ensure that the communications parameters are properly set.
3. Press [Alt-G] or click on [Go].
4. Commence dumping the magnetometer according to the documented
procedure.
Name of file in which to place dump (.XYZ assumed):
↓
Communications port: COM1
Baud rate: 9600
cleaR clear All Command Dos Help List eXit Go
G:\ENVIMAP
To Next Page
