Preparation
A2-8 ENVI-MAG Manual
Installing the terminal protective cover
A plastic cup-like assembly is include to slide over the base of the sensor(s) to
protect the terminal connections from the elements.
To install the cover:
1. Slide it over the sensor shaft — the widest end points towards the sensor.
2. Slide the supplied “O-ring” into the grove on the shaft to lock it into place.
To remove the cover, just reverse the above procedure. First remove the O-ring
and slide the cup away from the sensor.
Assembling the sensor staff
You can disregard this section if you are going to be using the ENVI-MAG in the
back-pack mode.
The sensor staff is shipped in four sections. These sections are located in layer 4
of the packing materials. You should note that one of the sections has a sealed
bottom, and you should start assembling the staff with this section.
Staff sections are assembled individually and connected to the sensors as follows:
1. Insert the male end partially into the female end and rotate counter-clock-
wise while gently pushing the two parts together.
2. When they are fully engaged firmly twist them clockwise against each other.
Note: The lower sections of the staff are interchangeable with those of the
SCINTREX MP-3/4 magnetometers. The section nearest to the sensor,
however, must be a section supplied with the ENVI-MAG. These sections
can be distinguished by their black ends.
