Keypad description
ENVI-MAG Manual A3-5
Instrument
Key Functions
Key Description
q
Turns the instrument on and off. Turning the instrument off
during a reading abruptly terminates a reading with the loss
of the current data.
w
Starts or stops an operation, such as data acquisition, data
dumping, data recall, etc.
*When the instrument is in the Notes operation, this button
acts as a “backspace” key to delete entries.
5
*Accesses the various setup displays. The actual setup menu
that will be displayed depends upon the display screen in
which this key is pressed.
1
*Accesses the Auxiliary Functions display allowing:
- setting of the LCD intensity,
- data output,
- locking of the setup parameters
- reprogramming of the main system software (EEPROM).
23
Moves the cursor to the left or up; to the right or down,
e
2 identical keys:
- opens and closes the parameter fields during setups
- opens and closes the scaling option field for the graphics
display
- toggles the sample rate in the walking type survey.
0
Allows escape from a deeper level in a program to a higher
level, ultimately to the top level, which is signified by the
Main operating display.
Aborts a data dump.
7
*Accesses the Info. Display, which allows:
- setting of data and time,
- entering of serial and job numbers, and operator identification,
- observation of memory availability.
