Instrument
A3-6 ENVI-MAG Manual
t
2 identical keys:
- scrolls sequentially through numeric data display pages,
- scrolls sequentially through graphic data display pages,
- moves the cursor from one sub-page to the next sub-page,
- moves the cursor to the next character location during note
entry,
- advances the station number by station separation in the
walking mode.
6
*Accesses the Note Entry display, which allows:
- the entry of five common notes (macros) to be recorded
repeatedly with selected readings
- the entry of unique notes to be recorded with a particular
reading.
4
Toggles the data display between numerical and graphic data
presentation during data acquisition only.
9
*Presents the Recall display for selection of:
- data item to be recalled
- setting of the starting location or time of the recall.
r
*Manually records measured data and notes in internal
memory.
8
Acts as the START key at a Tie-point. This is used for the
Tie-point line and loop mode corrections.
=-
Facilitates the scrolling forward or backward through a list of
items:
- allows sign entry to numbers,
- allows panning along a line of data during recall,
- increments or decrements the line and station number in
the Stop-and-Go mode.
1-9, ., A-Z
*Allows alpha-numeric entry for setups and notes.
BEEPER
PORT
This blank “key” in the upper left corner of the console is not
actually a key, but a flexible membrane to enhance the
loudness of the beeper.
Key Description
